Product Description


GENERAL CHARACTERISTICS :

Different sizes for :
Heights (mm) : 300 / 400 / 500 / 600 / 700 / 800 / 1000 / 1200
Widths (mm) : 200 / 300 / 400 / 500 / 600 / 800
Depths (mm) : 150 / 200 / 250 / 300

– Metallic welded monoblock body for extra strength.
– Bended side edges for better contact with door sealing.
– Narrow side bendings provide large usage area for internal mounting.
– Mounting plate can be pass through easily in or out of box.
– IP66 Protection level against dust & water ingress as per IEC EN60529
– IK10 Mechanical impact resistance as per IEC EN62262.
– Metal cabinets painted 70-90µ thickness RAL 7035 fine wrinkle with Nanotechnology to obtain upto 500 hours of salt spray test resistance.
– High chemical resistance.
– Multibended door structure to gain extra strength.
– Reversible doors with single/double lock.Zamak Hinges and edges have high-performance anti-corrosion treatment.
– Poly-urethane seal on door.
– EMKA branded high quality locks
– Vertical Mounting angles with holes on each 25 mm on door.
– Bottom cable entry.Sealed cable access panel at bottom
